Heritage Audio OST-6 6 Slot 500 Series Rack

$1,099.00
Shipping:
Free Shipping
Quantity:

Product Description

Heritage Audio OST-6 6 Slot 500 Series Rack

6-module 500 Series Rack with On Slot Technology for Per-slot Power Handling

- INCLUDES RACK KIT -

Please allow 10 - 14 days for delivery


A 500 Series Rack with Per-slot Power Handling

The Heritage Audio OST-6 is a 500 Series chassis that accommodates up to six modules. The OST-6 features the company's "On Slot" technology, which leverages next-generation power electronics to handle module power requirements on a per-slot basis. In the OST-6, each slot is spec'd with its own linear power-supply regulation stage, keeping each module isolated from the rest. Modules only share the metal enclosure. This is an effective method for eliminating common issues that can occur when sharing power between modules of different brands. The ruggedly built OST-6 ships with a handle and rubber feet for standalone use; or you can rackmount it using the included ears. Either way, you can count on the Heritage Audio OST-6 to deliver many years of trouble-free professional performance.

Heritage Audio OST-6 500 Series Rack at a Glance:
  • Protects your 500 series modules against power problems
  • Linear regulators ensure stable, precise power
  • Ample power for a 6-space rack
Protects your 500 series modules against power problems

Each slot in the OST-6 rack is completely isolated from the others, to ensure that the behavior of one power-hungry module doesn't affect the operation of the others. Over-current protection ensures that a sudden power draw won't fry your favorite mic preamp, while thermal protection for each slot protects modules against overheating. Unlike some 500 series racks that share electrical current across all slots, the Heritage Audio OST-6 rack ensures each module gets the exact power it needs, independent of the other modules.

Linear regulators ensure stable, precise power

The Heritage Audio OST-6 uses linear power regulators on each slot that are extremely precise, and this ensures power stability no matter what modules you're using. Voltages stay at +/-16 volts with an impressively low variance of only +/-0.1 volts. Each slot has red and green LEDs so you can easily check the power status for any module.

Ample power for a 6-space rack

With On Slot Technology, the OST-4 can provide 400mA per slot, or up to 700mA total across all slots (whichever is reached first). A total of 80mA of power is available for phantom power.

Heritage Audio OST-6 500 Series Rack Features:
  • 6-slot powered rack for 500 series modules
  • On Slot Technology regulates power to each slot individually, isolating each slot
  • Power capacity of 400mA per slot or up to 700mA across all slots, whichever is reached first
  • Phantom power available: 80mA total
  • Provides peace of mind when mixing modules with different power requirements from different manufacturers
  • Over-current and thermal protection for each slot
  • Audio inputs and outputs on gold plated XLR connectors
Power your 500 series modules with the Heritage Audio OST-6!

STL Pro Audio is the exclusive distributor for Heritage Audio in NZ. All products in full 12 months manufacture warranty.
